Product Description
- Specifically engineered for the Gen 3 (22-26) Suzuki Hayabusa
- Modified front section developed to complement the power delivery of the Gen 3
- Gen 2 to Gen 3 Hayabusa Full Exhaust Adapter Kit NOT Required
- 15" megaphone muffler with show-polished finish
- 2.25" (57.2 mm) outlet permanent baffle
- Larger diameter outlet provides increased exhaust flow
- High flow head pipe flange kit
- Maximized power gains on stock and modified engines
- Combine with a Dynojet PC6 and Brock's Performance 'Street-Style' Map for optimal performance
- Distinctive look and aggressive sound (optional noise suppressor sold separately)
- Each muffler is hand fabricated into a distinctive penta-diamond shape
- Muffler angles optimized for maximum ground clearance when cornering
- Customize with over 100 different color combinations
- Endcaps are produced by BST to ensure a perfect match to your wheels
- No fairing modifications required
- Aerospace quality, ultra lightweight stainless construction
- Incredible 78% weight savings vs. OEM exhaust system
- Two 12mm O2 bungs pre-installed to accommodate OEM oxygen sensors
- One 18mm O2 bung pre-installed to accommodate wideband O2 sensor (block off plug included)
- 3oz. tube of Permatex Ultra Copper® supplied with purchase
- Includes (emissions/PAIR) block off cap and instructions for decel-pop reduction
- Includes (4x) replacement graphite exhaust gaskets
- Includes Brock’s lifetime direct support package at no additional charge
- Click here to view logo plate color options
- Click here to view installation instructions
- Click here to view PAIR block-off instructions
- Click here to view Penta-Carbon Frequently Asked Questions (FAQ)
Recommended: Upgraded exhaust header bolts available here (a solution to the known issue of bent OEM hardware).
The NEW Brock’s Performance Penta-Carbon™ Stainless Steel Full Exhaust System is like no other. Make it your own! The Penta-Carbon™ is designed to be customized to your specifications. The heart of this customization is a beautiful five-sided carbon fiber endcap produced exclusively for Brock’s Performance by world-renowned carbon composite specialists Blackstone Tek (aka BST Carbon Fiber wheels). Not only is the carbon cap available in gloss or matte finishes, we have also expanded the offerings to match any available BST carbon fiber wheel custom ink colors, for a combination that is truly unique. Check this link for more information on Xirallic®, the shimmering ‘Ink’ finish applied to produce subtle colors that explode in direct sunlight: BST Custom Ink & Finish Options
Don’t have carbon fiber wheels yet? No problem, the colored end caps match the schemes of most brands: blue, red, and green… just to name a few.
‘What about the pipe,’ you ask? With sharp lines to match the aesthetic design trends of most modern sportbikes combined with the aggressive sound (hidden noise suppressor sold separately) Brock’s exhausts are known for, the Penta-Carbon™ shape won’t get lost in the crowd. They are available in show polished stainless or black ceramic-coated stainless. If you like the sound and power of our Alien Head mufflers, you will love this modern take on Brock’s legendary mindset.
Already have a Brock’s Performance Alien Head™, Short Meg™ or Slash Cut exhaust? No problem, the Penta-Carbon™ muffler is available separately (call for details) and designed to be an easy direct swap that takes only minutes.
As an added bonus for our #stupidfast friends, the Penta-Carbon™ muffler is also around 1/2 lb. (.22 kg) lighter than a comparable Alien Head or ShortMeg mufflers and outflows our Slash Cut mufflers.
And finally, the Penta-Carbon™ Mufflers are adorned with our new, more discreet, logo plates in a variety of colors as well as in our Stupid Fast (US Trademark No. 4,268,627) version: Logo Plate Color Options
Dyno Chart: Click image to enlarge
SAE Scale
Hayabusa (2022) Exhaust Weight Comparison
OEM Full Exhaust System:
- Mufflers w/ Clamps: 23.90 lb.
- Front Section (one piece): 17.55 lb.
(head pipes, catalytic converter, EXUP, tail pipe, etc.) - Heatshields and Hardware: 1.95 lb.
Total = 43.40 lb.
Penta-Carbon Full System:
- Muffler: 2.55 lb.
- Head Pipes (w/ flanges): 5.20 lb.
- Collector: 1.50 lb.
- Hardware: 0.40 lb.
Total = 9.65 lb.
Total Weight Savings = 33.75 lb. or 78% of OEM weight
